5.1 Navigation buttons

Field A on the home screen. See figure

Home screen. This button always takes you back to the home screen. See section 5 Home screen.

Operational settings. This is where the settings are entered for hydraulic row unit pressure. (If the machine is equipped with hydraulic row unit pressure and the function is activated). This is also where machines with liquid fertiliser controls its different modes. See section 8 Operational settings.

Statistics. Shows statistics of the machine’s operation as well as drilling performance for the current drilling operation. See section 9 Statistics.

Alarms. Press the button to access the alarms menu. The alarms menu shows a detailed description of the nature of the alarm; alarms can also be acknowledged here. The digit in the top left corner shows the number of activated alarms. See section10 Alarms .

General settings, calibration and configuration. These settings can only be accessed, for safety reasons, when the machine is stationary. With exception for machine calibration, that includes the radar calibration, and is done while the machine is in motion. No settings can be adjusted here during operation. See section 6 General settings.

Information. Displays information on software versions and status of GW, PDB and WorkStations (WSX). Detailed information for individual row units and various product motors can also be found here. See section 11 Information.
