5.1 Display for control and monitoring
Figure 1.
-
-
Driving speed (km/h)
-
-
Fan speed (rpm)
-
-
Safe Pressure (bar)
-
-
The active time the tools have been used in working position (ha)
-
-
Seed (kg/ha)
-
-
Fertiliser (kg/ha)
-
-
Virtual Hopper Level Function. Displays the indicated hopper and the level of the remaining seed / fertilizer in that particular hopper. This symbol is only displayed when a hopper has virtual level enabled.
Figure 2.
To edit the values for the control and monitoring click on the respective Icon. Also displayed are the values Virtual Hopper- Level function.
