9 Statistics

Important

Times are only recorded for when some type of sowing activity is in progress.

Go to the statistics menu by pressing the statistics field.

Figure 1.

The operations statistics menu shows statistics for the current drilling operation, for the current season and for the total service life of the seed drill.

Depending on whether the machine is equipped with a seed disc with fewer or more than 70 holes (see chapter 7.3 Calibration of the amount of delivered seed), what is displayed will be either skips/doubles or the percentage deviation from the specified feed rate.

Operating statistics

  1. Section A

    Current drilling operation

    Season

    Total

    number of sown seeds for the day

    number of sown seeds for the season

  2. Section B

    area sown

    area driven with the machine in work position

    average speed

  1. Reset statistics for current drilling operation and season (data in the grey box). Statistics for total service life cannot be reset.

  2. Resets the numbers for hectares.

Drilling performance

  1. Average number of skips and doubles for the current drilling operation and season.

  2. Sowing precision for current sowing operation. Variation coefficient for current sowing operation.

Drilling performance when the machine is equipped with a seed disc with more than 70 holes.

Figure 2.

  1. Percentage deviation from the specified feed rate.

  2. Average distance between seeds or seeds per hectare

Note

A value with a different background indicates that an alarm has been activated.

Note

Calculation of average sown amount (seeds per hectare) based only on active rows. If one or more rows are switched off due to tramlining, the average sown amount in the statistics menu will be different to reality. If an increased seed rate for adjacent tramlining is selected, this will affect the average sown amount in the statistics menu.
