7.5.1.2 Raised level measurement value

    904255 - 06 - en-GB

    7.5.1.2 Raised level measurement value

    1. Measure the distance from the drill discs to the ground. Enter the value in cm in the text field.

      Figure 1.

    2. Confirm with the arrow to the right.

    Parent topic: 7.5.1 Calibration of IDC – the function
    Previous topic: 7.5.1.1 Raised level
    Next topic: 7.5.1.3 Ground level
