12.1.2 Work display

Fields on the home screen:

1. Seed application rate Depending on the calibration method, either seed spacing or the amount of seed per hectare will be displayed.

2. Fertiliser application rate The feed can be switched off and on by pressing the fertiliser symbol.

3. Microgranulate application rate The feed can be switched off and on by pressing the micro-granulate symbol.

4. BioDrill rate The feed can be switched on and off by pressing the BioDrill symbol.

5. Liquid fertiliser rate The feed can be switched off and on by pressing the liquid fertiliser symbol.

6. Target feed rate By tapping the field for the feed rate, a pop-up window for variable adjustable application rate appears. See 13.10 Variable adjustable application rate

7. Press the field to switch values. The button can switch between:



   Driving speed



   Area meter



   Fan rotation speed, seed



   Fan rotation speed, fertiliser



   Fan speed, Central Fill



   Fan speed, BioDrill



   Air pressure



   Air pressure, Central Fill



   Air pressure, liquid fertiliser



   Pump speed, liquid fertiliser



   Mean ground contact (Only for machines with individual hydraulic row unit downforce)



   Average angle (Only for PCV)



   Mean seed quality (Only for TPK)

8. Press the field to switch value. The button can switch between the values in the list above.

9. Press the field to switch value. The button can switch between the values in the list above..

10. Bout marker switching Shows the current position of the bout marker arms. Press the field to switch bout marker. Switches manually or automatically depending on selection with the function button..

11. Tramlining The first number shows which phase of the tramlining cycle you are in. The second number is the number of tramlining cycles selected in the tramlining menu. Here it is possible to advance up through the bouts in numerical order. If ISOBUS is displayed on the button, it means that ISOBUS Tramline is activated.
