3.5.1 Button functions

Figure 1.

  1. Variable seed application rate: hold down button A and move UP/DOWN using buttons E and H.

    Shutting off the left half of the machine: hold down button A and press F.

    Shutting off the right half of the machine: hold down button A and press G.

  2. Variable fertiliser application rate: hold down button B and move UP/DOWN using buttons E and H.

    Enabling the left half of the machine: hold down button B and press F.

    Enabling the right half of the machine: hold down button B and press G.

  3. Alarms menu (displayed as long as the button is held down).

  4. Statistics menu (displayed as long as the button is held down).

  5. Lift stop (OFF/ON).

  6. Used to switch between high lift and full lift

  7. Bout marker switching. Switches manually or automatically depending on selection with the function button.

  8. Manual feed.
