15.2.1.2 Switching from working position to transport position

CAUTION

The machine must not rest on safety catches during transportation.

Figure 1.

  1. Switch off the fan.

  2. Press the transport position button and confirm your selection.

    Figure 2.

  3. Follow the on-screen instructions for raising and lowering. Once the machine is fully raised, the wing folding button is shown.

    Figure 3.

  4. Release the pin from position (B).

    -If the machine is equipped with hydraulic wing folding, undo the pin (B) on both sides.

Important

If the pins are tight: press the button for 3 seconds and adjust with the hydraulic lever to release the pressure on the pin.

  1. Rotate the wing section by hand into the transportation position.

    If the machine is equipped with hydraulic wing folding, turn the wings to the transport position using the hydraulic lever for wing folding.

    Figure 4.

  2. Lock the wings in the retracted position with the locking pins in position (A) on both sides.
